VERTEX Forged Piston for POLARIS RZR 900, RZR XP 1000, RZR XP 1000 HIGH LIFTER, RZR XP 1000 TURBO, RZR XP 1000 TURBO S 2015-2021

VERTEX offers this piston kit for POLARIS RZR 900, RZR XP 1000, RZR XP 1000 HIGH LIFTER, RZR XP 1000 TURBO, RZR XP 1000 TURBO S 2015-2021. The piston slides in the cylinder and takes the force of the air-fuel combustion, passing it to the connecting rod and crankshaft.

Why choose a forged piston?

Instead of simply being cast, a forged piston is hot-pressed under very high pressure and then machined: its metal is denser and free of air pockets.

• Stronger when hot: it copes better with high revs, overheating and detonation.
• Lighter for the same strength: less stress on the connecting rod and bearings.
• Good to know: depending on the alloy, it expands a little more and is fitted with more clearance; slight noise when cold is normal.
• Why does it cost more? Forging tools, full machining and surface treatments cost more than simple casting.

Why choose VERTEX?

Vertex has made its pistons in Italy since 1953 and has supplied KTM’s original pistons since 1996: molybdenum-disulphide coated skirt and Japanese rings. Its four-stroke pistons are forged from 2618 alloy.

When should you replace the piston on your POLARIS RZR 900?

Harder starting, loss of power, blue smoke, oil consumption or a knock when cold: these are the signs of a tired top end.

No manufacturer hour figure for this model. Cross-Mania guideline: compression check every 50 h in hard use and every 100 h for leisure.

Specifications and fitting tips

• Material: Aluminium
• Piston compression: High compression
• Rings Quantity: Set
• Stroke: 4T

Available in several sizes: choose the one that matches your cylinder (stamped size or measured bore). Diameters: A = 92.96 mm, B = 92.97 mm.

Cross-Mania tip: Measure the cylinder bore before ordering: the piston must match your cylinder size. Follow the manufacturer's break-in procedure and replace the top-end gaskets at the same time.

Also needed with this part

• 4-stroke engine oil : LIQUI MOLY 10W40 1 L · MOTUL 10W50

Compatibility

Check the exact model and year of your bike in the list below before ordering.

Fits:
POLARIS RZR 900 2018
POLARIS RZR 900 2017
POLARIS RZR 900 2016
POLARIS RZR 900 2015
POLARIS RZR XP 1000 2021
POLARIS RZR XP 1000 2020
POLARIS RZR XP 1000 2019
POLARIS RZR XP 1000 HIGH LIFTER 2020
POLARIS RZR XP 1000 HIGH LIFTER 2019
POLARIS RZR XP 1000 TRAILS & ROCKS 2020
POLARIS RZR XP 1000 TRAILS & ROCKS 2019
POLARIS RZR XP 1000 TURBO 2021
POLARIS RZR XP 1000 TURBO 2020
POLARIS RZR XP 1000 TURBO 2019
POLARIS RZR XP 1000 TURBO LE 2019
POLARIS RZR XP 1000 TURBO S 2021
POLARIS RZR XP 1000 TURBO S 2020
POLARIS RZR XP 1000 TURBO S 2019
