TECNIUM by DZE MOSFET Regulator for SUZUKI DR 650 RSE, DR 750 S, DR 800 S and GAS GAS WILD HP 450 1988-2008

TECNIUM offers this regulator rectifier for SUZUKI DR 650 RSE, DR 750 S, DR 800 S and GAS GAS WILD HP 450 1988-2008. The regulator rectifier is the link between the alternator and the battery. With the engine running, the alternator (stator and flywheel) produces an alternating current whose voltage rises with the revs.

Why replace the regulator?

The benefits:

• The battery charges again as you ride and starting becomes reliable again.
• A stable voltage protects the bulbs, the ignition unit and the fuel-injection electronics.
• MOSFET versions run cooler: a longer-lasting regulator on machines with little airflow.

When should you replace this part?

A battery that goes flat despite regular riding, bulbs that keep blowing, lights that vary with revs or a connector browned by heat: check the regulator.

Specifications and fitting tips

• Voltage: 12V
• Number of phases: Three-phase
• Output: DC
• Technology: MOSFET
• OEM type regulator
• Reliable and best quality part
• Manufacturer part number: 2543

Cross-Mania tip: Clean the connectors and the earth point, mount the regulator somewhere with airflow and its fins clear, then measure the voltage at the battery terminals with the engine running to confirm it is charging.

Compatibility

Check the exact model and year of your bike in the list below before ordering.

Fits:
GAS GAS WILD HP 450 2008
GAS GAS WILD HP 450 2007
GAS GAS WILD HP 450 2006
GAS GAS WILD HP 450 2005
GAS GAS WILD HP 450 2004
GAS GAS WILD HP 450 2003
SUZUKI DR 650 RSE 1996
SUZUKI DR 650 RSE 1995
SUZUKI DR 650 RSE 1994
SUZUKI DR 650 RSE 1993
SUZUKI DR 650 RSE 1992
SUZUKI DR 650 RSE 1991
SUZUKI DR 750 S 1989
SUZUKI DR 750 S 1988
SUZUKI DR 800 S 1995
SUZUKI DR 800 S 1994
SUZUKI DR 800 S 1993
SUZUKI DR 800 S 1992
SUZUKI DR 800 S 1991
SUZUKI DR 800 S 1990
