    WISECO Forged Piston for YAMAHA TTR 125, YZ 125 and FANTIC XE 125, XX 125 2005-2022
    WISECO Forged Piston for YAMAHA TTR 125, YZ 125 and FANTIC XE 125, XX 125 2005-2022

    WISECO Forged Piston for YAMAHA TTR 125, YZ 125 and FANTIC XE 125, XX 125 2005-2022

    Review (0)
    €167.90
    Tax Included
    En stock en nuestro proveedor, enviado en 2 a 5 días.

    The piston moves up and down in the cylinder to turn combustion into motion: this kit replaces it along with its rings, pin and clips.

    Quantity :
    In stock

    En stock en nuestro proveedor, enviado en 2 a 5 días.

    Wishlist
    Write your review

      WISECO offers this piston kit for YAMAHA TTR 125, YZ 125 and FANTIC XE 125, XX 125 2005-2022. The piston slides in the cylinder and takes the force of the air-fuel combustion, passing it to the connecting rod and crankshaft.

      Why choose a forged piston?

      Instead of simply being cast, a forged piston is hot-pressed under very high pressure and then machined: its metal is denser and free of air pockets.

      • Stronger when hot: it copes better with high revs, overheating and detonation.
      • Lighter for the same strength: less stress on the connecting rod and bearings.
      • Good to know: depending on the alloy, it expands a little more and is fitted with more clearance; slight noise when cold is normal.
      • Why does it cost more? Forging tools, full machining and surface treatments cost more than simple casting.

      Why choose WISECO?

      Wiseco has forged its pistons in Mentor (Ohio, USA) since 1941 and controls the whole process, from aluminium bar to the friction-reducing ArmorGlide skirt coating. Its pistons are developed with Team Honda HRC in Supercross (450 class since 2018).

      When should you replace the piston?

      Harder starting, loss of power, blue smoke, oil consumption or a knock when cold: these are the signs of a tired top end.

      No manufacturer hour figure for this model. Cross-Mania guideline: compression check every 20 h in hard use and every 40 h for leisure.

      Specifications and fitting tips

      • Material: Aluminium
      • Piston compression: Standard
      • Oversize Letter: 200
      • Stroke: 2T
      • Manufacturer part number: W845M05600

      Cross-Mania tip: Measure the cylinder bore before ordering: the piston must match your cylinder size. Follow the manufacturer's break-in procedure and replace the top-end gaskets at the same time.

      Also needed with this part

      Compatibility

      Check the exact model and year of your bike in the list below before ordering.

      Fits:
      FANTIC XE 125 2022
      FANTIC XE 125 2021
      FANTIC XX 125 2022
      FANTIC XX 125 2021
      YAMAHA TTR 125 2021
      YAMAHA YZ 125 2021
      YAMAHA YZ 125 2020
      YAMAHA YZ 125 2019
      YAMAHA YZ 125 2018
      YAMAHA YZ 125 2017
      YAMAHA YZ 125 2016
      YAMAHA YZ 125 2015
      YAMAHA YZ 125 2014
      YAMAHA YZ 125 2013
      YAMAHA YZ 125 2012
      YAMAHA YZ 125 2011
      YAMAHA YZ 125 2010
      YAMAHA YZ 125 2009
      YAMAHA YZ 125 2008
      YAMAHA YZ 125 2007
      YAMAHA YZ 125 2006
      YAMAHA YZ 125 2005

      WISECO
      W845M05600
