TECNIUM by DZE MOSFET Regulator for SUZUKI DL 650 V-STROM, DL 650 V-STROM ABS 2007-2012

TECNIUM offers this regulator rectifier for SUZUKI DL 650 V-STROM, DL 650 V-STROM ABS 2007-2012. The regulator rectifier is the link between the alternator and the battery. With the engine running, the alternator (stator and flywheel) produces an alternating current whose voltage rises with the revs.

Why replace the regulator?

The benefits:

• The battery charges again as you ride and starting becomes reliable again.
• A stable voltage protects the bulbs, the ignition unit and the fuel-injection electronics.
• MOSFET versions run cooler: a longer-lasting regulator on machines with little airflow.

When should you replace this part?

A battery that goes flat despite regular riding, bulbs that keep blowing, lights that vary with revs or a connector browned by heat: check the regulator.

Specifications and fitting tips

• Voltage: 12V
• Number of phases: Three-phase
• Output: DC
• Technology: MOSFET
• Three phase high performance regulator.
• Output current up to 50A
• Manufacturer part number: 2452

Cross-Mania tip: Clean the connectors and the earth point, mount the regulator somewhere with airflow and its fins clear, then measure the voltage at the battery terminals with the engine running to confirm it is charging.

Compatibility

Check the exact model and year of your bike in the list below before ordering.

Fits:
SUZUKI DL 650 V-STROM 2011
SUZUKI DL 650 V-STROM 2010
SUZUKI DL 650 V-STROM 2009
SUZUKI DL 650 V-STROM 2008
SUZUKI DL 650 V-STROM 2007
SUZUKI DL 650 V-STROM ABS 2012
SUZUKI DL 650 V-STROM ABS 2011
SUZUKI DL 650 V-STROM ABS 2010
SUZUKI DL 650 V-STROM ABS 2009
SUZUKI DL 650 V-STROM ABS 2008
SUZUKI DL 650 V-STROM ABS 2007
