ATHENA wheel bearing 6004 for SUZUKI DR-Z 400 S, RM 125, RM 250 and KAWASAKI KX 500 A, KX 500 B, KX 500 E from 1983 to 2013

ATHENA offers this wheel bearing 6004 for SUZUKI DR-Z 400 S, RM 125, RM 250 and KAWASAKI KX 500 A, KX 500 B, KX 500 E from 1983 to 2013. Each wheel spins on two bearings in the hub, separated by a spacer. Water and mud eventually damage them: play, rough spots, noise.

What is this bearing made of?

Races and balls in hardened chrome steel, 100Cr6 type, very hard and fatigue-resistant, protected by rubber seals.

• Double seal (2RS): a seal on each side, very well sealed against water and mud, essential off-road.
• Limit: slightly more drag than a metal-shielded bearing (ZZ), which spins more freely but seals far less well.
• Fitting: press or drift it in on the outer race, never hammer on the seal; keep the pressure washer away from the hubs.

Why choose ATHENA?

Athena, the Italian manufacturer founded in 1973, is an original-equipment supplier to manufacturers such as KTM and Ducati: the same standards for your replacement parts.

When should you replace the bearings?

Check the wheels for play at every wash with the wheel off the ground: a failing bearing can lock the wheel. Pressure washing forces water in and speeds up wear.

Specifications and fitting tips

• Outside diameter: 42 mm
• Inside diameter: 20 mm
• Model: 6004
• Style: Double seal
• Electric Motor Quality (EMQ): tight tolerances for a quiet, vibration-free bearing
• Sourced from leading bearing manufacturers

Cross-Mania tip: Always replace the bearings of a wheel together and check the spacer.

Compatibility

Check the exact model and year of your bike in the list below before ordering.

Fits:
KAWASAKI KX 500 A 1984
KAWASAKI KX 500 A 1983
KAWASAKI KX 500 B 1986
KAWASAKI KX 500 B 1985
KAWASAKI KX 500 C 1987
KAWASAKI KX 500 D 1988
KAWASAKI KX 500 E 2003
KAWASAKI KX 500 E 2002
KAWASAKI KX 500 E 2001
KAWASAKI KX 500 E 2000
KAWASAKI KX 500 E 1999
KAWASAKI KX 500 E 1998
KAWASAKI KX 500 E 1997
KAWASAKI KX 500 E 1996
KAWASAKI KX 500 E 1995
KAWASAKI KX 500 E 1994
KAWASAKI KX 500 E 1993
KAWASAKI KX 500 E 1992
KAWASAKI KX 500 E 1991
KAWASAKI KX 500 E 1990
KAWASAKI KX 500 E 1989
SUZUKI DR-Z 400 S 2013
SUZUKI DR-Z 400 S 2012
SUZUKI DR-Z 400 S 2004
SUZUKI DR-Z 400 S 2003
SUZUKI DR-Z 400 S 2002
SUZUKI DR-Z 400 S 2001
SUZUKI DR-Z 400 S 2000
SUZUKI RM 125 1999
SUZUKI RM 125 1998
SUZUKI RM 125 1997
SUZUKI RM 125 1996
SUZUKI RM 125 1995
SUZUKI RM 125 1994
SUZUKI RM 125 1993
SUZUKI RM 125 1992
SUZUKI RM 250 1999
SUZUKI RM 250 1998
SUZUKI RM 250 1997
SUZUKI RM 250 1996
SUZUKI RM 250 1995
SUZUKI RM 250 1994
SUZUKI RM 250 1993
SUZUKI RM 250 1992
SUZUKI RM 250 1991
SUZUKI RM 250 1990
SUZUKI RM 250 1989
