ATHENA wheel bearing 6203 for HONDA XL 500 S, XR 200 R, XR 250 L, XR 250 R, XR 500 R, XR 650 L from 1976 to 1999

ATHENA offers this wheel bearing 6203 for HONDA XL 500 S, XR 200 R, XR 250 L, XR 250 R, XR 500 R, XR 650 L from 1976 to 1999. Each wheel spins on two bearings in the hub, separated by a spacer. Water and mud eventually damage them: play, rough spots, noise.

What is this bearing made of?

Races and balls in hardened chrome steel, 100Cr6 type, very hard and fatigue-resistant, protected by rubber seals.

• Double seal (2RS): a seal on each side, very well sealed against water and mud, essential off-road.
• Limit: slightly more drag than a metal-shielded bearing (ZZ), which spins more freely but seals far less well.
• Fitting: press or drift it in on the outer race, never hammer on the seal; keep the pressure washer away from the hubs.

Why choose ATHENA?

Athena, the Italian manufacturer founded in 1973, is an original-equipment supplier to manufacturers such as KTM and Ducati: the same standards for your replacement parts.

When should you replace the bearings on your HONDA XR 200 R?

Check the wheels for play at every wash with the wheel off the ground: a failing bearing can lock the wheel. Pressure washing forces water in and speeds up wear.

Specifications and fitting tips

• Outside diameter: 47 mm
• Inside diameter: 17 mm
• Model: 6203
• Style: Double seal
• Electric Motor Quality (EMQ): tight tolerances for a quiet, vibration-free bearing
• Sourced from leading bearing manufacturers

Cross-Mania tip: Always replace the bearings of a wheel together and check the spacer.

Compatibility

Check the exact model and year of your bike in the list below before ordering.

Fits:
HONDA XL 200 R 1984
HONDA XL 200 R 1983
HONDA XL 350 1978
HONDA XL 350 1977
HONDA XL 350 1976
HONDA XL 350 K 1978
HONDA XL 350 K 1977
HONDA XL 350 K 1976
HONDA XL 350 R 1985
HONDA XL 350 R 1984
HONDA XL 500 R 1982
HONDA XL 500 S 1982
HONDA XL 500 S 1981
HONDA XL 500 S 1980
HONDA XL 500 S 1979
HONDA XR 200 R 1998
HONDA XR 200 R 1997
HONDA XR 200 R 1996
HONDA XR 200 R 1995
HONDA XR 200 R 1994
HONDA XR 200 R 1993
HONDA XR 200 R 1992
HONDA XR 200 R 1991
HONDA XR 200 R 1990
HONDA XR 200 R 1989
HONDA XR 200 R 1988
HONDA XR 200 R 1987
HONDA XR 200 R 1986
HONDA XR 200 R 1985
HONDA XR 200 R 1984
HONDA XR 200 R 1983
HONDA XR 200 R 1982
HONDA XR 200 R 1981
HONDA XR 250 L 1999
HONDA XR 250 L 1998
HONDA XR 250 L 1997
HONDA XR 250 L 1996
HONDA XR 250 L 1991
HONDA XR 250 L 1990
HONDA XR 250 L 1989
HONDA XR 250 L 1988
HONDA XR 250 L 1987
HONDA XR 250 L 1986
HONDA XR 250 R 1999
HONDA XR 250 R 1998
HONDA XR 250 R 1997
HONDA XR 250 R 1996
HONDA XR 250 R 1991
HONDA XR 250 R 1990
HONDA XR 250 R 1989
HONDA XR 250 R 1988
HONDA XR 250 R 1987
HONDA XR 250 R 1986
HONDA XR 250 R 1985
HONDA XR 250 R 1984
HONDA XR 250 R 1983
HONDA XR 250 R 1982
HONDA XR 250 R 1981
HONDA XR 500 1980
HONDA XR 500 1979
HONDA XR 500 R 1984
HONDA XR 500 R 1983
HONDA XR 500 R 1982
HONDA XR 500 R 1981
HONDA XR 650 L 1998
HONDA XR 650 L 1997
HONDA XR 650 L 1996
HONDA XR 650 L 1995
HONDA XR 650 L 1994
HONDA XR 650 L 1993
