ATHENA wheel bearing 6003 for KTM SX 85, SUZUKI RM 125, HONDA CR 125 R and YAMAHA YZ 125 from 1982 to 2017

ATHENA offers this wheel bearing 6003 for KTM SX 85, SUZUKI RM 125, HONDA CR 125 R and YAMAHA YZ 125 from 1982 to 2017. Each wheel spins on two bearings in the hub, separated by a spacer. Water and mud eventually damage them: play, rough spots, noise.

What is this bearing made of?

Races and balls in hardened chrome steel, 100Cr6 type, very hard and fatigue-resistant, protected by rubber seals.

• Double seal (2RS): a seal on each side, very well sealed against water and mud, essential off-road.
• Limit: slightly more drag than a metal-shielded bearing (ZZ), which spins more freely but seals far less well.
• Fitting: press or drift it in on the outer race, never hammer on the seal; keep the pressure washer away from the hubs.

Why choose ATHENA?

Athena, the Italian manufacturer founded in 1973, is an original-equipment supplier to manufacturers such as KTM and Ducati: the same standards for your replacement parts.

When should you replace the bearings?

Check the wheels for play at every wash with the wheel off the ground: a failing bearing can lock the wheel. Pressure washing forces water in and speeds up wear.

Specifications and fitting tips

• Outside diameter: 35 mm
• Inside diameter: 17 mm
• Model: 6003
• Style: Double seal
• Electric Motor Quality (EMQ): tight tolerances for a quiet, vibration-free bearing
• Sourced from leading bearing manufacturers

Cross-Mania tip: Always replace the bearings of a wheel together and check the spacer.

Compatibility

Check the exact model and year of your bike in the list below before ordering.

Fits:
HONDA CR 125 R 1994
HONDA CR 125 R 1993
HONDA CR 125 R 1992
HONDA CR 125 R 1991
HONDA CR 125 R 1990
HONDA CR 250 R 1994
HONDA CR 250 R 1993
HONDA CR 250 R 1992
HONDA CR 250 R 1991
HONDA CR 250 R 1990
HONDA CR 500 R 1994
HONDA CR 500 R 1993
HONDA CR 500 R 1992
HONDA CR 500 R 1991
HONDA CR 500 R 1990
KTM SX 105 2011
KTM SX 50 2017
KTM SX 50 2016
KTM SX 50 2015
KTM SX 50 MINI 2016
KTM SX 50 MINI 2015
KTM SX 65 2017
KTM SX 65 2016
KTM SX 65 2015
KTM SX 65 2011
KTM SX 65 2010
KTM SX 65 2009
KTM SX 65 2008
KTM SX 65 2007
KTM SX 65 2006
KTM SX 65 2005
KTM SX 65 2004
KTM SX 65 2003
KTM SX 65 2002
KTM SX 65 2001
KTM SX 65 2000
KTM SX 85 2011
KTM SX 85 2010
KTM SX 85 2009
KTM SX 85 2008
KTM SX 85 2007
KTM SX 85 2006
KTM SX 85 2005
KTM SX 85 2004
KTM SX 85 2003
KTM XC 65 2010
KTM XC 65 2009
KTM XC 65 2008
KTM XC 65 2007
KTM XC 65 2006
KTM XC 65 2005
KTM XC 65 2004
KTM XC 65 2003
KTM XC 65 2002
KTM XC 85 2010
KTM XC 85 2009
KTM XC 85 2008
SUZUKI RM 125 2002
SUZUKI RM 125 2001
SUZUKI RM 125 2000
SUZUKI RM 125 1999
SUZUKI RM 125 1998
SUZUKI RM 125 1997
SUZUKI RM 125 1996
SUZUKI RM 125 1995
SUZUKI RM 125 1994
SUZUKI RM 125 1993
SUZUKI RM 125 1992
SUZUKI RM 125 1991
SUZUKI RM 125 1990
SUZUKI RM 125 1989
SUZUKI RM 250 2002
SUZUKI RM 250 2001
SUZUKI RM 250 2000
SUZUKI RM 250 1999
SUZUKI RM 250 1998
SUZUKI RM 250 1997
SUZUKI RM 250 1996
SUZUKI RM 250 1995
SUZUKI RM 250 1994
SUZUKI RM 250 1993
SUZUKI RM 250 1992
SUZUKI RM 250 1991
SUZUKI RM 250 1990
SUZUKI RM 250 1989
YAMAHA YZ 125 1995
YAMAHA YZ 125 1994
YAMAHA YZ 125 1993
YAMAHA YZ 125 1992
YAMAHA YZ 125 1985
YAMAHA YZ 125 1984
YAMAHA YZ 125 1983
YAMAHA YZ 125 1982
YAMAHA YZ 250 1995
YAMAHA YZ 250 1994
YAMAHA YZ 250 1993
YAMAHA YZ 250 1992
