ATHENA Engine Bearing for GAS GAS EC 250, EC 300 and APRILIA RX 125 1995-2015

On GAS GAS EC 250, EC 300 and APRILIA RX 125 from 1995 to 2015, the ATHENA MS300620160C4 engine bearing fits in place of the original part. In a motocross engine, the bearings spin fast and take hard knocks. Replacing a tired bearing at the right time saves the crankcase or the gearbox from damage.

Specifications

• Brand: ATHENA
• Manufacturer part number: MS300620160C4
• EAN code: 7316571401102
• Type: 6206C4
• Weight: 200 g
• Engine: 2-stroke

When to replace it?

• Bearing noise or engine rumble.
• Play or tight spot when turning the bearing by hand.
• Signs of overheating or rust on the races.

During an engine rebuild, or as soon as a bearing shows play or tight spots.

Fitting tips

1. Heat the crankcase (around 100 to 120 °C) to remove the old bearing and fit the new one without force.
2. Only push on the race that is the tight fit: outer race in the crankcase, inner race on the shaft.
3. Check which way round it goes if the bearing has a shielded side.
4. Close up with new gaskets or a complete engine gasket kit.

Why ATHENA?

Founded in 1973 near Vicenza, Athena is an Italian engine gasket specialist that has made its gaskets on its own production lines since day one, as well as a renowned manufacturer of pistons and cylinder kits. The brand supplies original equipment to manufacturers such as KTM, Ducati, Fantic, Piaggio and Triumph, and is a partner of the MXGP motocross world championship.

Spare parts and items to plan

• Complete engine gasket kit : CENTAURO · ATHENA
• Engine oil seals : INNTECK · ALL BALLS
• Gearbox oil : LIQUI MOLY 10W30 1 L · LIQUI MOLY 1 L

Frequently asked questions

Is the bearing OEM quality?
It is supplied by Athena; the bearing brand (SKF, KOYO, NTN…) is given in the specifications when it is known.

Compatibility

Check the exact model and year of your bike in the list below before ordering.

Fits:
APRILIA RX 125 1998
APRILIA RX 125 1997
APRILIA RX 125 1996
APRILIA RX 125 1995
GAS GAS EC 250 2015
GAS GAS EC 250 2014
GAS GAS EC 250 2013
GAS GAS EC 250 2012
GAS GAS EC 250 2011
GAS GAS EC 250 2010
GAS GAS EC 250 2009
GAS GAS EC 250 2008
GAS GAS EC 250 2007
GAS GAS EC 250 2006
GAS GAS EC 250 2005
GAS GAS EC 250 2004
GAS GAS EC 250 2003
GAS GAS EC 250 2002
GAS GAS EC 250 2001
GAS GAS EC 250 2000
GAS GAS EC 250 1999
GAS GAS EC 250 1998
GAS GAS EC 250 1997
GAS GAS EC 300 2015
GAS GAS EC 300 2014
GAS GAS EC 300 2013
GAS GAS EC 300 2012
GAS GAS EC 300 2011
GAS GAS EC 300 2010
GAS GAS EC 300 2009
GAS GAS EC 300 2008
GAS GAS EC 300 2007
GAS GAS EC 300 2006
GAS GAS EC 300 2005
GAS GAS EC 300 2004
GAS GAS EC 300 2003
GAS GAS EC 300 2002
GAS GAS EC 300 2001
GAS GAS EC 300 2000
GAS GAS EC 300 1999
GAS GAS EC 300 1998
GAS GAS EC 300 1997
